故障改變執行流或權限Fault changes execution or permissions
Boot path、guard read、wrapper 與 lock state 可能在 fault 下失去原先假設。Boot paths, guard reads, wrappers and lock states can lose their assumptions under fault.
TSMC OIP 2026 展會專題版 · SECURE STORAGE ARCHITECTURETSMC OIP 2026 EVENT EDITION · SECURE STORAGE ARCHITECTURE
保護永久資料，
但不永久保存 root keyProtect permanent data
without permanently storing the root key
以 RP2350 公開案例界定 physical-access threat model，再由 SRAM PUF root、AES-256 encrypted OTP、address scrambling 與 Secure Controller 組成可防守的 system response；所有尚待 target-silicon evidence 關閉的限制同時保持可見。Use the public RP2350 case to define a physical-access threat model, then compose a defensible system response from an SRAM-PUF root, AES-256 encrypted OTP, address scrambling and a Secure Controller—while keeping every target-silicon evidence gap visible.
摘要 · 實證收斂核心ABSTRACT · REFINED FOR EVIDENCE
問題是 persistent observability；
答案是分離 storage 與 secretThe problem is persistent observability;
the answer is storage–secret separation
RP2350 的公開結果顯示，permission、wrapper、fault detector 與 antifuse bit-cell opacity 都不能單獨成為最終防線。當 OTP bits 直接代表可用 root key、firmware secret 或 security configuration，成功 readout 的後果會非常接近完整 compromise。The public RP2350 results show that permissions, wrappers, fault detectors and assumed antifuse opacity cannot stand alone as the final barrier. When OTP bits directly encode a usable root key, firmware secret or security configuration, successful readout can approach full compromise.
Secure Storage 將 device-unique root 在上電時由 SRAM PUF 重建，以 AES-256 保護 OTP data，並用 address scrambling 與 Secure Controller 管理 mapping、provisioning、access 與 lifecycle。它的設計目標不是讓 OTP 永遠無法觀察，而是讓觀察結果停在 scrambled ciphertext。Secure Storage reconstructs a device-unique root from SRAM PUF behavior at power-up, protects OTP data with AES-256, and uses address scrambling plus a Secure Controller to govern mapping, provisioning, access and lifecycle. Its design goal is not to make OTP forever unobservable, but to make observation stop at scrambled ciphertext.
01 · 公開攻擊實證01 · PUBLIC ATTACK EVIDENCE
RP2350 用來界定
physical-access threat modelRP2350 defines
a physical-access threat model
公開結果包含 voltage、laser、EM fault 與 FIB／PVC invasive analysis；這是控制與物理兩條平行 attack paths，不是所有 OTP 都會重現的單一因果鏈。它們支持同一條設計規則：memory-cell secrecy 不應是最後一道 confidentiality boundary。Public results include voltage, laser and EM faults plus FIB/PVC invasive analysis. These are parallel control and physical attack paths—not one causal chain that every OTP will reproduce. They support one design rule: memory-cell secrecy should not be the final confidentiality boundary.
FIB/PVC 逼近位元單元狀態還原FIB/PVC approached cell-state recovery
公開結果讀出相鄰 bit pair 的 OR；完整逐 bit recovery 被認為原理上可能，但未被示範。The public result recovered the OR of adjacent bit pairs. Complete per-bit recovery was considered possible in principle, but was not demonstrated.
實體讀出應止步於受保護資料Readout should end at protected data
只有在 encryption、scrambling、reconstruction、policy 與 lifecycle controls 都成立時，storage-state recovery 才應停在 protected data。Only when encryption, scrambling, reconstruction, policy and lifecycle controls all hold should storage-state recovery stop at protected data.
直接來源：Direct sources: Raspberry Pi challenge results ↗ · IOActive FIB/PVC analysis ↗
02 · 系統架構回應02 · SYSTEM RESPONSE
四個功能不是清單；
它們共同改變 attack consequenceFour functions are not a checklist;
together they change attack consequence
每一層只解決正確的問題：PUF 降低永久 key residency；AES 提供 confidentiality；scrambling 提高 mapping 成本；controller 約束 transaction 與 lifecycle。Each layer solves the right problem: PUF reduces permanent key residency; AES provides confidentiality; scrambling raises mapping cost; the controller constrains transactions and lifecycle.
Root 不永久存放The root is not permanently stored
上電重建 device-unique root；runtime path、helper data 與 zeroization 仍須驗證。Reconstruct a device-unique root at power-up; runtime path, helper data and zeroization still require assurance.
密文成為持久狀態Ciphertext becomes the persistent state
真正的 confidentiality boundary；需要 FI／SCA 與 key-derivation evidence。The real confidentiality boundary; FI, SCA and key-derivation evidence remain required.
切斷 logical-to-physical mappingBreak the logical-to-physical map
增加 recovery 與 reconstruction 成本，但不取代 encryption。Raises recovery and reconstruction cost, but never replaces encryption.
約束可用明文的時間窗Bound the usable-plaintext window
管理 provisioning、APB access、error response、lifecycle 與 software contract。Governs provisioning, APB access, error response, lifecycle and the software contract.
組合系統推論COMPOSED SYSTEM INFERENCEOTP 讀出 → 混淆密文 ≠ 可用機密OTP readout → scrambled ciphertext ≠ usable secret
斷電靜態 → 上電重建 → 授權存取 → 零化銷毀Power-off → reconstruct → authorize → zeroize
Absent-at-rest 只處理永久 root target；runtime residency、reset interruption 與 zeroization 必須另行驗證。Absent-at-rest removes a persistent root target; runtime residency, reset interruption and zeroization still require separate evidence.
重建材料不是 root-key 備份Reconstruction material is not a root-key backup
公開 helper data 仍需要 leakage、integrity、replay、rollback 與 fault evidence。Public helper data still requires leakage, integrity, replay, rollback and fault evidence.
預先整合架構有助於減少跨 IP 交付斷層與邊界安全風險Pre-integration mitigates cross-IP hand-off and boundary security risks
Contractual ownership、qualification support 與 product-response scope 仍須在 target configuration 確認。Contractual ownership, qualification support and product-response scope must still be confirmed for the target configuration.
架構來源：Architecture source: Synopsys Secure Storage Solution ↗
03 · 實證檢驗門檻03 · EVIDENCE GATES
Architecture 是起點；
silicon evidence 才能形成 ResultsArchitecture is the start;
silicon evidence creates Results
OIP 報告應把結果分為 public evidence、vendor disclosure、system inference 與 validation gap；不要把設計意圖寫成完成驗證。The OIP report should separate public evidence, vendor disclosure, system inference and validation gaps; design intent must not masquerade as completed validation.
RP2350 實體攻擊實證 (FIB/PVC)RP2350 attack evidence
公開案例支持威脅模型與問題重要性。Public cases support the threat model and urgency.
架構與先進製程節點規格主張Architecture & node claims
產品頁支持功能、AES-256、PUF root、APB 與 OTP node availability。Product pages support functions, AES-256, PUF root, APB and OTP node availability.
第三方實作驗證與安全認證證據Implementation and Assurance Evidence
PVT 邊界單元篩選、高低溫 Aging、LFI/Glitch 故障注入、DPA/CPA 功耗側信道衰減、頂層主動金屬屏蔽、單週期 Zeroization、以及 NIST SP 800-90B/208 與 CC AVA_VAN.5 證據鏈尚需具體封閉。Extreme-PVT marginal cells, thermal aging, LFI/glitch injection, DPA/CPA attenuation, active top-metal shield, single-cycle zeroization, and formal evidence chains (NIST SP 800-90B/208, CC AVA_VAN.5) must still close for the target configuration.
可防守的現階段結論The defensible conclusion today
此 architecture 合理地把 OTP physical recovery 與 usable-secret recovery 分離；但特定產品的 resistance、certification 與 residual risk 必須以 target implementation evidence 確認。The architecture credibly separates physical OTP recovery from usable-secret recovery; resistance, certification and residual risk for a specific product require target-implementation evidence.
節點來源：Node source: Synopsys OTP platform evidence ↗
04 · OIP 共同決策04 · OIP DECISION
把報告從 solution pitch，
收斂成共同 evidence planMove beyond a solution pitch;
align on a shared evidence plan
TSMC OIP 的價值不是只列 N5／N3，而是把 exact macro、node、integration boundary 與 assurance deliverables 對齊。The OIP value is not simply listing N5/N3; it is aligning the exact macro, node, integration boundary and assurance deliverables.
確認 target configurationConfirm the target configuration
Node · OTP macro · capacity · read mode · qualification · Secure Storage release status
封閉 SoC boundaryClose the SoC boundary
Power/reset · APB privilege · DFT/debug · provisioning · firmware API · lifecycle
定義 evidence acceptanceDefine evidence acceptance
FI · SCA · invasive · PVT/aging · zeroization · residual risk · report owner
建議簡報結尾：Recommended close: 同意 target node 與 configuration 的 evidence closure plan，而不是宣稱所有攻擊已被消除。Agree the evidence-closure plan for the target node and configuration—rather than claiming every physical attack has been eliminated.
保護永久資料，
但不永久保存 root keyProtect permanent data
without permanently storing the root key
以架構確立隔離，以證據建立保證。Architecture establishes the separation. Evidence establishes the assurance.
